Aries Cerat - Concero 25 - Power Amplifiers

Aries Cerat - Concero 25 - Power Amplifiers

A$0.00

Our first Prestige Series amplifier is the Concero Direct Heated Tube Monoblock amplifiers.

Using top line design, material and building techniques, we managed to get pretty close to our Reference line amplifier performance, but in a more manageable, funds and size wise design.

We tried to come with a design that has all the sonic virtues of only the best of the best SE amplifiers, but with absolute none of their shortcomings. We strongly believe we succeed so.

Driving the output tube, is a major task, which almost all SET amplifiers fall short, using tubes not adequate to the task,tubes with high Rp and small current swing capabilities. What we choose to use is a small amp ,consisting of the special quality Siemens E280F super-tube, with it’s own power and bias supply.

This ultra wide-bandwidth/very high trans-conductance tube is transformer coupled to the grid of the output tube using a very wide-bandwidth inter stage transformer. No RC coupling is used in any of our amplifiers.

Output is rated @ 30W, via a massive output transformer, with 4 and 8 ohm taps.

The output transformer weighs more than many SET amplifier weigh at whole. The highest quality massive core of the output transformer used in the design, is mandatory for delivering true undistorted higher and lower bass, and driving any speaker through complex musical content. Many SET amplifiers get distortion when driving speakers with complex music,because of core saturation.Our output transformer can easily take 60W at 20Hz ,so at 25W intermodulation aftifacts are next to null.

Separate power supplies are used throughout our design, using 4 toroidal transformers rated at over 1100VA total.Separate toroidals are used for driver stage,output stage,filaments and bias circuits.

Driver and output is ground-choke regulated and energy banks are over 4000 joule per channel.

Specifications:
• Full Power sensitivity: 1Vrms
• Noise floor: <-100db A-weighted
• THD: < -70db @ 60% Full power
• Power Bandwidth: 15Hz ~ 80Khz -3db @ 25W
• Tube list: 1x RCA 813, 1x Siemens E280F
• Power Consumption @ idle: 250W

Dimensions: 560 mm W x 420 mm D x 390 mm H
Weight is 70Kg each, unpacked.
